Two modes, Freely Selectable.
Equipped with a built-in screen, it
can be operated directly without a
central control system.
Includes a power-assist switch,
quick-access buttons, and front
indicator for easy and efficient use.
can be operated directly without a
central control system.
Includes a power-assist switch,
quick-access buttons, and front
indicator for easy and efficient use.
Compact form allows it to travel
underneath rack units, enabling
flexible navigation.
Capable of lifting cargo from the
center underneath, requiring
minimal path clearance.
underneath rack units, enabling
flexible navigation.
Capable of lifting cargo from the
center underneath, requiring
minimal path clearance.
Key
Features
1
600 KG
Payload Capacity
Payload Capacity
With a 600 KG payload
capacity, the T600 is built for
heavy-payload material
transport, greatly reducing
delivery frequency and
improving efficiency per trip.
capacity, the T600 is built for
heavy-payload material
transport, greatly reducing
delivery frequency and
improving efficiency per trip.
2
Narrow Aisle
Intelligent Traffic Strategy
Intelligent Traffic Strategy
Based on path width and the robots‘ real-time load dimensions, the system intelligently determines whether to apply single-lane or dual-lane traffic modes.
3
Rack Group Recognition
Powered by advanced navigation and perception systems, the T600 series intelligently identifies target storage locations and autonomously performs pick-and-place operations.
4
Support
VDA5050 Protocol
VDA5050 Protocol
Compatible with the VDA5050 standard communication protocol, enabling collaborative scheduling with other compliant robots and systems.
5
Idle Elevator Priority Scheduling
In busy multi-elevator scenarios, the system intelligently calls idle elevators first. The system monitors elevator status in real time, prioritizing available elevators to avoid peak-time congestion and resource waste.
Specifications
Download Brochure
Maximum load
600 KG (1322 lbs)
Weight
112 KG / 247 lbs
Machine Dimensions
960 mm * 500 mm * 1350 mm
(37.8 in * 19.7 in * 53.1 in)
Charging Time
2 H (from 0% to 90%)
Run-time
12 H (none load)
Operating Environment
0°C ~ 40°C (32°F ~ 104°F)
Battery Capacity
30 AH
Navigation Method
VSLAM + LiDAR SLAM
Minimum Passability
70 cm (27.6 in)
Max. surmountable height
10mm (0.39 in)
Cruise Speed
0.2~1.2 m/s (0.67~3.94 ft/s)
Max. surmountable gap
35 mm (1.38 in)
